Puritan Bennet 980

Puritan Bennet 980

Аппарат ИВЛ высокого класса

Описание

Спецификация

Галерея

Вентилятор NPB 980™ – это следующая ступень в эволюции аппаратов для искусственной вентиляции легких. Среди достоинств вентилятора 980 особо выделяется его универсальность, в сочетании с индивидуальным подходом к физиологическим особенностям вентиляции у любых категорий пациентов. Вентилятор 980 предоставляет врачу широчайший арсенал методов респираторной терапии. Вместе с тем, методы управления вентилятором чрезвычайно просты.

Predicted body weight (PBW);Pediatric: 3.5 kg to 35 kg (7.7 lb to 77 lb), Adult: 25 kg to 150 kg (55 lb to 330 lb) Modes;Assist/Control (A/C), Synchronized Intermittent Mandatory Ventilation (SIMV), Spontaneous (SPONT), BiLevel 2.0 or Continuous Positive Airway Pressure (CPAP) Software;Leak Sync, BiLevel 2.0, Proportional Assist™* Ventilation Plus (PAV™*+) Mandatory breath types;Volume Control (VC), Pressure Control (PC) or Volume Control Plus (VC+) Spontaneous breath types;Pressure Support (PS), Volume Support (VS), Proportional Assist™* Ventilation Plus (PAV™*+) and Tube Compensation Vent type;Invasive or Noninvasive Pressure support (PSUPP);0 to 70 cmH2O Rise time %;1% to 100% Expiratory sensitivity (ESENS);1% to 80% in PS and VS; 1 L/min to 10 L/min with PAV™*+ Tidal volume (VT);25 to 2,500 mL Respiratory rate (f);1.0 to 100 1/min pediatric/adult Peak inspiratory flow (VMAX);3 to 150 L/min for adult; 3 to 60 L/min for pediatric Flow pattern;Square or descending ramp Plateau time (TPL);0.0 to 2.0 seconds Inspiratory pressure (PI);5 to 90 cmH2O Constant during rate change;I:E ratio, TI, TE for PC or VC+, TH:TL ratio, TH, TL in BiLevel mode Inspiratory time (TI);0.2 to 8.0 seconds I:E ratio;≤ 1:299 to 4:1, in BiLevel mode TH:TL range is 1:299 to 149:1 Expiratory time (TE);≥ 0.2 seconds Trigger type;Pressure (PTRIG) or flow (VTRIG) Pressure sensitivity (PSENS);0.1 to 20 cmH2O Flow sensitivity (VSENS);0.2 to 20 L/min for pediatric/adult O2%;21% to 100% Apnea ventilation;Apnea mandatory type-Volume Control (VC) or Pressure Control (PC) Apnea flow pattern;Square or descending ramp Apnea peak inspiratory flow (VMAX);3.0 L/min to 60 L/min for pediatric, 3.0 L/min to 150 L/min for adult Apnea tidal volume (VT);≥ 25 mL to 2500 mL for pediatric/adult Apnea inspiratory pressure (PI);5 cmH2O to 90-PEEP cmH2O Apnea inspiratory time (TI);0.2 to 8.0 seconds Apnea interval (TA);10 to 60 seconds or OFF in CPAP Apnea respiratory rate (f);2.0 to 40 1/min Apnea O2%;21% to 100% Apnea expiratory time (TE);≥ 0.2 seconds Disconnect sensitivity (DSENS);20% to 95% or OFF when Leak Sync disabled, when Leak Sync is enabled: 1 to 40 L/min for pediatric, 1 to 65 L/min for adult Humidification type;Heat-moisture exchanger (HME), nonheated expiratory tube or heated expiratory tube Humidifier volume;100 to 1,000 mL Patient circuit type;Pediatric or adult
